DS8 Series Intelligent Sensor Meter

Description

1) Signal input: AC 0-5A,4-20mA,0-10V,0-100mV,Rt,Pt100,Tc,etc. input combination of AC and DC.eg,AV600/AA5, DC80/DA4; configurable by software;

2) Application:signal input can select digits or peak value holding fuction,20 segments non-linearity input,applicate to any non-linearity sensors andresistance 0-100k, DC power meter,etc. for example, DW8-NNNN4DC80/DA4,DW8-NNN4DV150/DA3. when input 0-5k RTD can act as electrical ruler;

3) Output:up to 4 alarm output, UPPER/LOW or betweens can be setted freely. isolate analoge output:0-10mA/4-20mA,configurable by software.

4) Power supply:+12V OR 24V/30mA,etc..

5) Communication :RS232 or RS485 Modbus RTU protocol,connectable with PLC.

6) Regular model:DS8-NB DS8-IDV300/75mV DS8-DV300/75mV DS8-RRNB DS8-IRRB DS8-RRR,etc.

7) Used in 2-wire transmitter,pressure sensor,weighing sensor,thermocouple,resistance,remote voltage meter,IR sensor,also act as ohmmeter.

8) Size: DS4:48*48*80 DS6:48*96*80 DS8:96*48*80 DS7:72*72*100 DS9:96*96*100 DS10:160*80*70; case class:IP65. 10) Power:regualr:80~265V AC/DC,12~30V AC/DC should indicate when ordering.
